DTH RC Drill Pipes and Casing

3 3.5 4 5 inch 76mm 89mm 102mm 114mm DTH Drill Pipes and 108 114 140 168 178 194 219 245 273 325 mm Casing

CGEO provides drill pipes and casing for DTH drilling. DTH drill pipes include 76mm(3") 89mm(3.5") 102mm(4") 114mm(4.5mm) etc. Casing includes 108mm 114mm 140mm 168mm 178mm 183mm 194mm 219mm 245mm 273mm 325mm etc.

CGEO manufactures our DTH drill pipes and casing with high quality raw material and heat treatment.

CGEO provides drill pipes and casing for DTH drilling. DTH drill pipes include 76mm(3") 89mm(3.5") 102mm(4") 114mm(4.5mm) etc. Casing includes 108mm 114mm 140mm 168mm 178mm 183mm 194mm 219mm 245mm 273mm 325mm etc.

CGEO manufactures our DTH drill pipes and casing with high quality raw material and heat treatment.

APPALICATION

-Open-pit mining, underground mining, tunneling, anchoring, furnace tapping, tunnel construction, hydropower projects, quarrying and construction etc.

DTH DRILL PIPE OFFERINGS:

Outer Diameter (mm[in])	Thread Pin/Box	Wall Thickness (mm[in])	Wrench Flat (mm[in])	Length m[Ft]	Weight kg[lbs]
76[3]	API 2 3/8 Reg	6.5[0.2559]	57[2.2441]	3[9.8]	40[88.2]
76[3]	API 2 3/8 Reg	8.5[0.3346]	57[2.2441]	3[9.8]	48[105.8]
89[3 1/2]	API 2 3/8 Reg	6.5[0.2559]	70[2.7559]	3[9.8]	48[105.8]
89[3 1/2]	API 2 3/8 Reg	8.5[0.3346]	70[2.7559]	3[9.8]	58[127.9]
102[4]	API 3 1/2 Reg	6.5[0.2559]	83[3.2677]	3[9.8]	56[123.5]
102[4]	API 3 1/2 Reg	8.5[0.3346]	83[3.2677]	3[9.8]	67[147.7]
114[4 1/2]	API 3 1/2 Reg	6.5[0.2559]	95[3.7402]	3[9.8]	63[138.9]
114[4 1/2]	API 3 1/2 Reg	8.5[0.3346]	95[3.7402]	3[9.8]	76[167.5]
127[5]	API 3 1/2 Reg	8.5[0.3346]	108[4.2520]	3[9.8]	86[189.6]
127[5]	API 3 1/2 IF	8.5[0.3346]	1084.2520]	3[9.8]	86[189.6]
140[5 1/2]	API 3 1/2 Reg	9.2[0.3622]	121[4.7638]	3[9.8]	101[222.7]
152[6]	API 4 1/2 Reg	8.5[0.3346]	133[5.2362]	3[9.8]	105[231.5]
168[6 5/8]	API 4 1/2 Reg	10[0.3937]	149[5.8661]	3[9.8]	132[291.0]
178[7]	API 4 1/2 Reg	10[0.3937]	159[6.2598]	3[9.8]	140[308.6]

RC DRILL PIPE OFFERINGS:

Outer Diameter (mm[in])	Thread Connection	Wall Thickness (mm[in])	Wrench Flat (mm[in])	Flat Width (mm[in])	Length m[Ft]
89[3 1/2]	REMET3.5	6.5[0.2559]	79[3.1102]	50[1.9685]	3[9.8]
89[3 1/2]	REMET3.5	8.5[0.3346]	79[3.1102]]	50[1.9685]	3[9.8]
102[4]	REMET4.0	6.5[0.2559]	91[3.5827]	50[1.9685]	3[9.8]
	METZKE4.0	6.5[0.2559]	91[3.5827]	50[1.9685]	3[9.8]
	REMET4.0	8.5[0.3346]	91[3.5827]	50[1.9685]	3[9.8]
	METZKE4.0	8.5[0.3346]	91[3.5827]	50[1.9685]	3[9.8]
114[4 1/2]	REMET4.5	8.5[0.3346]	103[4.0551]	50[1.9685]	3[9.8]
114[4 1/2]	METZKE4.5	8.5[0.3346]	103[4.0551]	50[1.9685]	3[9.8]
127[5]	REMET4.5	8.5[0.3346]	116[4.5669]	50[1.9685]	3[9.8]
127[5]	METZKE4.5	8.5[0.3346]	116[4.5669]	50[1.9685]	3[9.8]

DTH CASING OFFERINGS:

Outer Diameter (mm[in])	Wall Thickness (mm[in])	Length (m[Ft])	Weight (kg[lbs])
108[4.2520]	7[0.2756]	1.5[4.9]	27.1[59.7]
114[4.4882]	6.5[0.2559]	1.5[4.9]	31[68.3]
127[5.0000]	6.5[0.2559]	1.5[4.9]	35[77.2]
127[5.0000]	9.5[0.3740]	1.5[4.9]	43.7[96.3]
146[5.7480]	10[0.3937]	1.5[4.9]	53.7[118.4]
168[6.6142]	10[0.3937]	1.5[4.9]	62.4[137.6]
178[7.0079]	9[0.3543]	1.5[4.9]	61.8[136.2]
194[7.6378]	10[0.3937]	1.5[4.9]	73[160.9]
219[8.6220]	10[0.3937]	1.5[4.9]	85.7[188.9]
273[10.7480]	10[0.3937]	1.5[4.9]	107.7[237.4]
325[12.7953]	12[0.4724]	1.5[4.9]	154.7[341.1]
