Eccentric & Concentric Casing Systems

76mm 89mm 114mm 127mm 140mm 146mm 168mm 178mm 194mm 219mm 245mm 254mm 273mm 325mm eccentric(ODEX) and concentric casing systems

CGEO provides eccentric(ODEX) and concentric casing systems. Includes 76mm 89mm 114mm 127mm 140mm 146mm 168mm 178mm 194mm 219mm 245mm 254mm 273mm 325mm casing series. Eccentric(OEDX) and concentric casing systems are used loose and unconsolidated or other easy collapse formations.

CGEO manufactures eccentric(ODEX) and concentric casing systems. Includes 76mm 89mm 114mm 127mm 140mm 146mm 168mm 178mm 194mm 219mm 245mm 254mm 273mm 325mm casing series. Eccentric(OEDX) and concentric casing systems are used loose and unconsolidated or other easy collapse formations.

CGEO eccentric(ODEX) and concentric casing systems are manufactured with high quality alloy steel. We also use the advanced heat-treatment.

APPALICATION

-Mining,quarry blasting hole borehole drilling

-Water well,deep hole well,oil and gas open hole drilling

-Foundation and piling drilling

ECCENTRIC(ODEX) CASING SYSTEM OFFERINGS:

Type	Drill Pipes	Minimum Inside Diameter of Casing Shoe (mm[in])	Reamed Diameter (mm[in])	Casing Dimensions			Suitable Hammer Type	Weight (kg[lbs])
Type	Drill Pipes	Minimum Inside Diameter of Casing Shoe (mm[in])	Reamed Diameter (mm[in])	Outside Diameter (mm[in])	Inside Diameter (mm[in])	Wall Thickness (mm[in])	Suitable Hammer Type	Weight (kg[lbs])
ODEX108	76[3”]	86[3.3858]	117[4.6062]	108[4.2520]	94[3.7008]	7[0.2756]	COP32 COP34 DHD3.5 BR3 MACH303	12.2[26.9]
ODEX114	76[3”] 89[3.5”]	92[3.6620]	125[4.9213]	114[4.4882]	101[3.9764]	6.5[0.2559]	COP32 COP34 DHD3.5 BR3 MACH303	14[30.9]
ODEX127	89[3.5”]	100[3.9370]	138[5.4331]	127[5.0000]	109[4.2914]	9[0.3543]	COP32 COP34 DHD3.5 BR3 MACH303	15.9[35.1]
ODEX140	114[4.5”]	117[4.6063]	155[6.1024]	140[5.5118]	126[4.9606]	7[0.2756]	COP44 DHD340 MACH44 M40 SD4 XL4 QL4	27.9[61.5]
ODEX168	114[4.5”]	138[5.4331]	180[7.0866]	168[6.6142]	148[5.8268]	10[0.3937]	COP54 DHD350 MACH50 M50 SD5 QL50	42[92.6]
ODEX178	114[4.5”]	147[5.7874]	192[7.5591]	178[7.0079]	158[6.2205]	10[0.3937]	COP54 DHD350 MACH50 M50 SD5 QL50	44.1[97.2]
ODEX183	114[4.5”]	153[6.0236]	196[7.7165]	183[7.2047]	163[6.4173]	10[0.3937]	COP54,COP64 DHD350,DHD360 MACH50 M50,M60 SD5,SD6 QL50,QL60	56[123.5]
ODEX194	114[4.5”]	162[6.3780]	206[8.1102]	194[7.6378]	174[6.8504]	10[0.3937]	COP64 DHD360 M60 SD6 QL60	61.7[136.0]
ODEX219	114[4.5”]	187[7.3662]	234[9.2126]	219[8.6220]	199[7.8346]	10[0.3937]	COP64 DHD360 M60 SD6 QL60	75.1[165.6]
ODEX245	114[4.5”]	210[8.2677]	263[10.3543]	245[9.6457]	225[8]	10[0.3937]	COP84 DHD380 SD8 QL80	113.3[249.8]
ODEX273	114[4.5”]	241[9.4882]	305[12.0079]	273[10.7480]	253[9.9606]	10[0.3937]	COP84 DHD380 SD8 QL80	137.2[302.5]
ODEX325	114[4.5”]	282[11.1024]	350[13.7795]	325[12.7953]	300[11.8110]	12.5[0.4921]	SD10 NUMA100 DHD112 DHD380	225.5[497.1]

CONCENTRIC CASING SYSTEM OFFERINGS:

(R): Retrievable (P): Permanent

Type	Suitable Hammer Type	Pilot Bit Max Outer Diameter (mm[in])	Ring Bit Outer Diameter (mm[in])	Through Bit Max Outer Diameter (mm[in])	Casing Dimensions			Weight (kg[lbs])
Type	Suitable Hammer Type	Pilot Bit Max Outer Diameter (mm[in])	Ring Bit Outer Diameter (mm[in])	Through Bit Max Outer Diameter (mm[in])	Outside Diameter (mm[in])	Inside Diameter (mm[in])	Wall Thickness (mm[in])	Weight (kg[lbs])

CT76	R32	57[2.2441]	84[3.3071](R) 88[3.4646](P)	39[1.5354]	76[2.9921]	62[2.4409]	7[0.2756]	3.2[7.1]
CT89	T38	70[2.7559]	96[3.7795](R) 100[3.9370](P)	58[2.2835]	89[3.5039]	73[2.8740]	8[0.3150]	5.8[12.8]
CT114	T45	92[3.6220]	122[4.8031](R) 126[4.9606](P)	80[3.1496](R) 84[3.3071](P)	114[4.4882]	94[3.7008]	10[0.3937]	7.5[16.5]
CT127	T45	105[4.1339]	136[5.3543](R) 142[5.5906](P)	90[3.5433](R) 93[3.6614](P)	127[5.0000]	107[4.2126]	10[0.3937]	10[22.0]
CT140	T45/T51	116[4.5669]	148[5.8268](R) 161[6.3386](P)	97[3.8189]	140[5.5118]	120[4.7244]	10[0.3937]	15[33.1]

CD114	COP32 COP34 DHD3.5 BR3 MACH303	92[3.6220]	122[4.8031](R) 126[4.9606](P)	80[3.1496](R) 84[3.3071](P)	114[4.4882]	94[3.7008]	10[0.3937]	10[22.0]
CD127	COP32 COP34 DHD3.5 BR3 MACH303	105[4.1339]	136[5.3543](R) 142[5.5906](P)	90[3.5433](R) 93[3.6614](P)	127[5.0000]	107[4.2126]	10[0.3937]	16[35.3]
CD140	COP44 DHD340 MACH44 M40 SD4 XL4 QL40	116[4.5669]	148[5.8268](R) 161[6.3386](P)	97[3.8189]	140[5.5118]	120[4.7244]	10[0.3937]	21[46.3]
CD146	COP44 DHD340 MACH44 M40 SD4 XL4 QL40	124[4.8819]	154[6.0630](R) 165[6.4961](P)	110[4.3307]	146[5.7480]	126[4.9606]	10[0.3937]	22[48.5]
CD168	COP54 DHD350 MACH50 M50 SD5 QL50	141[5.5512]	180[7.0866](R) 188[7.4016][P]	125[4.9213](R) 127[5.0000](P)	168[6.6142]	142.6[5.6142]	12.7[0.5000]	27[59.5]
CD178	COP54 DHD350 MACH50 M50 SD5 QL50	150[5.9055]	186[7.3228](R) 196[7.7165](P)	131[5.1575](R) 135[5.3150](P)	178[7.0079]	152.6[6.0079]	12.7[0.5000]	32.5[71.6]
CD194	COP62 COP64 DHD360 M60 SD6 XL6 QL60	166[6.5354]	202[7.9528](R) 214[8.4252](P)	145[5.7087]	194[7.6378]	168.6[6.6378]	12.7[0.5000]	42.5[93.7]
CD219	COP62 COP64 DHD360 M60 SD6 XL6 QL60	191[7.5197]	228[8.9764](R) 243[9.5669](P)	170[6.6929]	219[8.6220]	193.6[7.6220]	12.7[0.5000]	58[127.9]
CD245	COP84 DHD380 SD8 QL80	214[8.4252]	254[10.0000](R) 268[10.5512](P)	195[7.6772]	245[9.6457]	219.6[8.6457]	12.7[0.5000]	78[172.0]
CD254	COP84 DHD380 SD8 QL8	224[8.8189]	265[10.4331](R) 276[10.8661](P)	203[7.9921]	254[10.0000]	228.6[9.0000]	12.7[0.5000]	84.5[186.3]
CD273	COP84 DHD380 SD8 QL8	241[9.4882]	286[11.2598](R) 298[11.7323](P)	223[8.7795]	273[10.7480]	247.6[9.7480]	12.7[0.5000]	100[220.5]
CD325	COP84 DHD380 SD8 QL8	292[11.4961]	338[13.3071](R) 380[14.9606](P)	276[10.8661]	325[12.7953]	299.6[11.7953]	12.7[0.5000]	135[297.6]
