top hammer shank adapters and button bits

:Atlas Copco Boart Longyear Furukawa Ingersoll Rand Sandvik Tamrock Shank Adapters and R28 32 38 T38 T45 T51 43mm to 152mm Button Bits

Description
Inquiry

Top Hammer Shank Adapters & Button Bits

Atlas Copco Boart Longyear Furukawa Ingersoll Rand Sandvik Tamrock Shank Adapters and R28 32 38 T38 T45 T51 43mm to 152mm Button Bits

CGEO provides wide range of top hammer shank adapters and button bits. Our shank adapters could be compatible with Atlas Copco, Boart Longyear, Furukawa, Ingersoll Rand, Sandvik/Tamrock etc. Our button bits are from 43mm to 152mm with R28 R32 R38 T38 T45 T51 threads.

CGEO manufactures shank adapters and button bits with high quality alloy steel. We also use the advanced heat-treatment.

CGEO provides wide range of top hammer shank adapters and button bits. Our shank adapters could be compatible with Atlas Copco, Boart Longyear, Furukawa, Ingersoll Rand, Sandvik/Tamrock etc. Our button bits are from 43mm to 152mm with R28 R32 R38 T38 T45 T51 threads.

CGEO manufactures shank adapters and button bits with high quality alloy steel. We also use the advanced heat-treatment.

APPALICATION

-Open-pit mining, underground mining, tunneling, anchoring, furnace tapping, tunnel construction, hydropower projects, quarrying and construction etc.

TOP HAMMER SHANK ADAPTER OFFERINGS:

ATLAS COPCO:

BBC 42, BBC 44, BBC 100, BBC 54, BBC120, BBE 57, COP 125, COP 130, COP 131, COP 131E, COP 131EB, COP 738, COP A15, COP 925/928, COP 932/938, COP 1028, COP 1032, COP 1036, COP 1038, COP 1238, COP 1132, COP 1140, COP 1240, COP 1240EX, COP 1338EX, COP 1432, COP 1532, COP 1435, COP 1440, COP 1838, COP 1550, COP 2238, COP 1838AW, COP 1640, COP 1640EX, COP 1838EX, COP 1838MUX/HUX, COP 1840, COP 1840EX, COP 1850, COP 1850EX, COP 2150, COP 2150EX, COP 2550, COP 2150EX, COP 2550EX, COP 2160, COP 2160EX, COP 2540EX, COP 2550, COP 2550EX, 2550UX, COP 2560, COP 2560EX, COP 3038, COP 3060ME, COP 3060MEX, COP 3060MUX, COP 4050, COP 4050ME, COP 4050MEX ETC.

BOART LONGYEAR:

HE 65, HE 150, HD 155, S 140, S36IR ETC.

FURUKAWA:

HD 90, HD 190, HD 609, HD 612 RP, PD 200 ETC.

INGERSOLL RAND:

350, Hydrastar 200, VL 120, VL 140, EVL 130, YD 90 M, YH 65, YH 70, YH 65 RP, YH 80A , YH 80A RP, YH 95 RP, YH 100 RP, YH 110 V, YH 135 ETC.

SANDVIK/TAMROCK:

HLX 1, HLX 3, HLX 5, HFX 5, L 400, L 500, L 600, L 750, 438 LS, 438 TS, HL 538, HL 538 L, L 550 S, 438, 538, HL 300, HL 300 S, HL 500 F, HL 500, HL 500 S, HL 550 S, HL 560 S, HL 600, HL 600 S, HL 645, HL 645 S, HL 700, HL 800, HL 1000, HL 1000 PE-65, HL 1500, HL 1500 PE-65, HL 1560 T-65, HL 1500-60, 1500-T60, HL 1500-80, 1560-T80, HL 1500 ETC.

TOP HAMMER SHANK ADAPTER THREAD OFFERINGS:

R28 R32 R38

T38 T45 T51

SR28 SR32 SR38

TC35 TC42

ST58 ST68

T-WiZ60

BUTTON BITS OFFERINGS:

Bit Diameter (mm[in])	Thread Connection	No.×Button Size(mm)		Flushing Holes		Approx Weight (kg[lbs])
Bit Diameter (mm[in])	Thread Connection	Gauge	Front	Side	Front	Approx Weight (kg[lbs])
43[1 11/16”]	R28	5×10	2×9	2	1	0.9[2.0]
44[1 47/64”]	R32	6×9	3×8	1	3	0.92[2.0]
45[1 3/4”]	R28/R32	6×9	3×9	1	3	0.95[2.1]
48[1 7/8”]	R32	5×11	2×9	2	1	0.98[2.2]
51[2”]	R32	6×10	3×9	-	3	1.00[2.2]
54[2 1/8”]	R32	5×11	2×9	2	1	1.15[2.5]
57[2 1/4”]	R32	6×11	3×10	-	3	1.30[2.9]
64[1 1/2”]	R32/T38	6×12	3×12	2	1	1.60[3.5]
76[3”]	R32/R38/T38/T45	8×12	4×11	2	1	2.60[5.7]
89[3 1/2”]	T38/T45/T51	8×12	4×12+2×10	-	3	4.60[10.1]
102[4”]	R32/T38/T45/T51	8×14	6×12	1	3	5.60[12.3]
115[4 1/2”]	T45/T51	8×14	7×13	-	4	6.00[]13.2
127[5”]	T45/T51	8×14	7×13	1	2	6.50[14.3]
140[5 1/2”]	T51	8×16	7×14	1	2	8.90[19.6]
152[6”]	T51	8×16	8×14	1	2	10.00[22.0]
