casing shoes

casing shoes,rod shoes, casing bits,BW NW HW PW HWT PWT casing shoe, NQ HQ PQ rod shoe.

Description
Inquiry

Casing shoe is a part of casing system.The casing shoes are threaded to the end of the outer drill string for penetration through overburden. It helps in seating the outer drill string into the bedrock, providing a tight seal for the drilling fluids to return to the surface. casing shoes can be used to ream the casing downward when advancing a casing string in an existing hole with the rod string still in place.

casing shoes are heavy duty diamond products which can match up to the toughest formations. With the use of very resilient matrix to optimize diamond retention, they will hold up in very abrasive, unfriendly formations

Casing Shoe Offerings:

Size	Outside Set Diameter		Inside Set Diameter
Size	mm	inch	mm	inch
W/WTSeries
BW	75.20	2.961	60.20	2.370
NW	91.80	3.614	76.00	2.992
HW/HWT	117.40	4.622	99.70	3.925
PW/PWT	143.40	5.646	123.40	4.858

Rod Shoe Offerings:

Size	Outside Set Diameter		Inside Set Diameter
Size	mm	inch	mm	inch
Q Series
NQ	75.20	2.961	60.20	2.370
HQ	91.80	3.614	76.00	2.992
PQ/PHD	117.40	4.622	99.70	3.925
